เครื่องบันทึก HiLook 8 ch DVR-E08G-B

Brand

HILOOK

Model

DVR-E08G-B

Video Compression

H.265 Pro/H.265

Encoding Resolution

1080p Lite/720p/WD1/4CIF/CIF

Frame Rate

Main stream:
1080p Lite/720p/WD1/4CIF/CIF@25 fps (P)/30 fps (N)
Note:
1080p Lite/720p is 15 fps by default
Sub-stream:
4CIF@15fps; CIF/QVGA@25 fps (P)/30 fps (N)

Video Bitrate

According to the actual scene, scene-adaptive bitrate control technology would
automatically allocates appropriate bitrate to ensure the stability of recording period.

Stream Type

Video, Video & Audio
Note: In order to protect privacy, the device will only record video (without audio) by
default. If you want to record audio, you shall manually enable audio recording. For
operation details, refer to the user manual.

Audio Compression

G.711u

Audio Bitrate

64 Kbps

IP Video Input

2-ch
Up to 5 MP resolution
Support H.265+/H.265 IP cameras

Analog Video Input

8-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection

HDTVI Input

1080p25, 1080p30, 720p25, 720p30

AHD Input

1080p25, 1080p30, 720p25, 720p30

CVBS Input

Support

HDCVI Input

1080p25, 1080p30, 720p25, 720p30

HDMI Output

1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz

VGA Output

1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz

Video Output Mode

HDMI/VGA simultaneous output

Audio Input

8-ch via coaxial cable

Audio Output

1-ch via HDMI

Total Bandwidth

72 Mbps
Incoming bandwidth: 1 Mbps

Network Protocol

TCP/IP, DHCP, HiLookVision, DNS, DDNS, NTP, SADP, SMTP, NFS, UPnP™, HTTPS

Network Interface

1, RJ45 10/100 Mbps self-adaptive Ethernet interface

Power Supply

12 VDC, 1 A

Consumption

≤ 6.2 W (with eSSD)

Dimension (W × D × H)

Weight

≤ 0.5 kg (with eSSD, 1.1 lb.)
